Capacity:***0J、***0J
Applications：This type of testing machine is specially used
for dynamic tear testing (DT test) of metallic
materials
Standard:GB/T
********7《金属材料动态撕裂试验方法》；
ASTM E*****3《Standard Test Method for
Dynamic Tear Testing of Metallic Materials》.
Capacity：****0J、****0J、****0J、****0J、*****0J
Applications：
For dynamic DT test or DWTT testing
of ferritic steel, pipeline steel and other metallic
materials。
Comply with standards: GB/T
********7《铁素体钢落锤撕裂试验方法》；
ASTM E*****3《Standard Test Method for Drop-Weight Tear Tests
of Ferritic Steels》；
API RP*5L***6《Conducting Drop-Weight Tear Tests on Line
Pipe》；
GB/T ********2《摆锤式冲击试验机的检验》；
JJG *******7 《摆锤式冲击试验机》.
Features:
The pendulum impact tangentially, greatly reduces vibration to the
surrounding environment.
Be able to accurately measure the
absorbed energy and other test parameters.
Full automatic processing allows that
automatically controlling, feeding, impacting, clutching, easy to
operate
Be equipped with full-closed
enclosure with nice appearance, test in the closed space in the
machine to protect the safety of operator
High rigid frame, easy to adjust the
accuracy of entire equipment, effectively reduce the impact
vibration.
Apply high precision bearing shaft
assembly made from carbon steel, effectively prevent the vibration
and friction.
Cycloid pin wheel reducer is used for
driving clutch, simple structure, high deceleration and strong
anti-overload, high efficiency, small size,
maintenance-free.
Convenient in maintenance and
reliable in safety with smaller size, higher efficiency and higher
protection.
Servo motor release pendulum
hammer,constant torque output with high precision, speed is
adjustable.
A damper is equipped to prevent
strong bump when clutching, prolong service life of equipments and
improve the safety
Apply automatic specimen feeding
system combined with computer and software, automatic operation can
be realized.
Apply pneumatic brake for braking the
pendulum, avoid the clutch working in high speed, greatly extend
the life.
A large LCD monitor may real-time
displays the test data, components status and other
parameters
Apply PLC to control pendulum,
acurate and intelligent control of every movements of test
mahcine,
High precision rotary encoder to
measure striker real time position, the angle resolution up to
0.**5°
Technical
Specification
| Model | PTM****-D1 | PTM****-D1 | PTM****-D1 | |
| Max Impact energy | ***0J | ***0J | ****0J、****0J、****0J | |
| Raising angle | **5° | *1.6°、**6.3°、**5° | ||
| Distance from striking center to supporting center | ***0mm | ***0mm | ***0mm | |
| Impact speed | 6.**7m/s | 7.***8m/s |
5.**8、7.**8、8.**3m/s |
|
| Supporting anvil span | **5±0.8mm | **4±0.8mm | ||
| Radius of supporting anvils | *2.7±0.8mm | *0.8±0.8mm | ||
| Width of striker | *7mm | *0.8±0.8mm | ||
| Weight | Approx ***0kg | Approx ****0kg | Approx ****0kg | |
| Power supply | Five-wire, Three-phase, **0V±*0%, *0Hz,*0A **0V/*0Hz±*0% *5A | Five-wire, Three-phase, **0V±*0%, *0Hz,*0A | Five-wire, Three-phase, **0V±*0%, *0Hz,*0A | |
