Micro-Computer Control Electronic Testing Machine

详情

Features and uses:
MZ-***0A, the MZ-***0B micro-controlled electronic universal testing machine using computer control, sensor force measurement system Levelcontrol, belt drive. Its novel structure, accurate digital processing,simple operation, easy maintenance. This machine is the high-precisiontest of mechanical properties of metals and non-metallic materials, multi-purpose testing machine can accurately Determination of physical properties data of a variety of materials under tension, with a forcevalue (or peak force), displacement Value, range three display windows.Parameter and limit protection function.Can be used forscientific research departments, colleges, universities and industrial and mining enterprises and production quality of the mechanical properties of various materials Test. MZ-***0A displays the forcevalue, the MZ-***0B display force value and displacement value.

Technical parameters:

1 Maximum range: 5KN

2 within ± 1.0% of the force value accuracy: Indication

3 Speed ​​range: 5mm/min****0mm/min speed permissible error range: ± 1.0% of indication within

4 effective stretching distance（without clamp）: **0mm

5 Deformation measurement accuracy: within ±      0.5% of the indication(optional)

6 the displacement measurement accuracy: within ± 1.0% of theindication (optional)

7 Power supply voltage: AC**0V±5% *0Hz

8 Dimensions: **0mm × **0mm × ***3mm

9 Weight: *5kg
