Universal testing machine

详情

Name： TH - ***1S Computer Servo Control Universal Testing Machine
Summary：
TH****1S Computer Servo Control Universal Testing Machine during testing is a full digital power, displacement, speed three closed-loop control, using the Imported AC Servo Motor and control-driven system, with Italy Haitec gear box and Taiwan TBI Precision Ball Screw drive, to achieve transmission efficiency and noise ratio of the best results.
This machine mainly used for detection of non-metallic materials, Solar module and etc, tensile, compression, bending, tearing, shear, bending and weld strength performance.  At the same time according to GB, ISO, JIS, ASTM, DIN, and provide a variety of standards testing and data processing.
This machine is widely used in engineering plastic, solar PV, wire and cable, auto parts, electronic products ,paper and packaging industry. Scientific research institutes, universities, industrial enterprises, technical supervision, inspection and arbitration departments ideal test equipment.
Standard：
GB/T ***0、GB/T ***2、ASTM D**8 、ASTM D**0、ISO **8、ISO**7、DIN*****4、DIN*****2 etc.

Technical Specifications:
A、  Main technical parameters:
1、  Capacity：**0N、**0N、**0N、1kN、2kN、5kN、*0kN、*0KN；
2、 Accuracy grade：0.5 ；
3、 Load range：0.2%***0%FS；
4、 Load accuracy：within ±0.5%；
5、 Load resolution：1/±*****0of capacity；
6、 Deformation measurement range：0.2%***0%FS；
7、 Deformation measurement accuracy：within ±0.5% of reading；
8、 Deformation resolution：0.***1mm；
9、 Displacement value error：within ±0.5%；
*0、 Displacement resolution：0.***5mm；
*1、 Loading speed range：0.****0%FS/s；
*2、 Loading speed accuracy：within  ±1% of setting；
*3、 Deformation speed range：0.***5%FS/s；
*4、 Deformation speed accuracy：within ±1% of setting；
*5、 Crosshead speed：0.******0mm/min；
*6、 Crosshead speed accuracy：when the speed rate < 5mm/min, within±1.0% of setting ;when the speed rate ≥5mm/min, within ±0.5% of setting;
*7、 constant load, constant deformation, constant displacement control range: 0.5%****0%FS
*8、 constant load, constant deformation, constant displacement control accuracy: when setting value ≥*0%FS, within ±0.1%; when setting value <*0%FS,within ±1%;
*9、 Effective width：**0mm；
*0、 Effective space：***0mm（excluded fixture）；
*1、 Dimension：**0×**0×***0（mm）；
*2、 Net Weight：**0kg；
*3、 Power supply：AC **0V,*0Hz 1kw
B、 Control and data processing software features:
1、 Advanced chip integration technology, professional design of data acquisition amplification system with high integration, stability and reliability, and simplicity.  Control software can automatically obtain Tensile strength, Yield strength, Breaking strength, Elastic modulus and Elongation test data, open the formula editor can automatically calculate the course of any given test point force, stress, displacement, deformation, etc. data results.  The trial process control and data processing line with the corresponding metal materials and nonmetal materials, national standards.
2、 Control: Set speed, Set displacement, Set load ,Set Load growth rate , Set growth rate of stress, Set Strain, Set Growth rate of strain control by way of optional;
3、 Automatic reset: After the trial began, auto-zero measurement system;
4、 Automatic transmission: According to the load size automatically switch to the appropriate range to ensure the accuracy of measurements;
5、 Auto Save: automatic test data and test conditions for Save, to prevent the loss of data due to forget to save;
6、 Volume test: the same parameters of the samples, a set can be completed by a batch of test;
7、 Display: curve with the experimental data and the process of dynamic display;
8、 Curve traversal: After the test, the curve can be re-analyzed with the mouse to find the corresponding point on the test curve data;
9、 Curve selection: choose the stress - strain, force - displacement, force - time, displacement - time curve display and printing;
*0、 Units switch: power units: (g, kg, N, lb), stress units: (kg/mm2, N/mm2, Mpa , lbf/in2) displacement units: (m, mm, in)
*1、 Test Report: Users can request the test report format of the programming and printing, and can output WORD/ EXCEL/PDF documents;
*2、 Safety protection: over the maximum load of 2 to *0%, the automatic realization of security;
*3、 Can automatically detect, calculate the mechanical properties of the sample, the analysis process can be manual intervention, according to the requirements of relevant standards to amend the automatic results to improve the accuracy of the data;
Standard accessories with machine:
1、 load sensors: U.S. MKCELLDS load cells,  *0KN   1 set;
2、 Disp. sensor system: Optical Encoder  1 set;
3、 Data processor:TM***0 *4 bit closed-loop measurement control board  1 set;
4、 Test Software: Top-Test measurement control system English/version 1 set;
5、 Power System: AC Servo Motor and control drive system  1 set;
6、 Transmission: Italy Haitec Gearbox and TBI precision ball screw 1 set;
7、 Test Fixture: develop the fixture according to sample 1 set;
8、 Windows 7 test software(English version)                                                              1set;
9、 Data analysis special computer                                                                              1set.
