离岸价格
获取最新报价100000 ~ 300000 USD / Piece
|1 Milligram Minimum Order
国家:
China
型号:
The vertical multistation combination machine tool is a highefficiency, highprecision automated processing equipment, especially suitable for the mass production of complex parts such as brass valves. It integrates drilling, boring, tapping and other proc
离岸价格:
100000 ~ 300000 USD / Piece 获取最新报价
位置:
China
最小订单价格:
100000 per Piece
最小订单:
1 Milligram
包装细节:
20-40 ft container
交货时间:
1-3 months
供应能力:
20 Piece per Month
付款方式:
T/T, L/C
產品組 :
-
联系人 Ms. Fiona
Dalian, Liaoning
|
1 Core Features 1.1 Highrigidity structural design The bed and foot structures are cast with HT**0, and the main body of the power head is cast with QT**0 as a whole. It is aged three times according to the standard process to eliminate internal stress to the greatest extent and ensure accuracy. The hydraulic twoway synchronous clamp design has uniform clamping force to avoid deformation or scratches of brass materials caused by uneven clamping force. 1.2 Multistation collaborative processing The typical station layout is a threeaxis rotation combination, for example: Station 1: drilling (to meet the basic hole processing requirements of the valve body); Station 2: boring (to improve the inner hole accuracy and surface quality); Station 3: tapping (to complete thread processing). The station can be flexibly adjusted according to product requirements to support singledirection processing of specialshaped parts. 1.3. Efficient automation configuration 1.4. Each functional power head can complete drilling and tapping simultaneously, so that the blank of the processed product can be processed into a finished product at one time. For customers who produce in large quantities and need to assemble special machines to process parts, the power head is used with a cylinder. Whether it is heavy cutting or precision cutting, it can not only shorten the assembly time and improve production efficiency, but also achieve the maximum economic benefit of cost saving. The loading and unloading method supports manual operation or robot visual imaging system, and a simple manipulator can be selected to reduce manual intervention and improve the level of automation. 1.5. In view of the characteristics of brass that it is easy to process but requires antisticking knives, it is equipped with drilling and boring air blowing, tapping spray cooling, and saponification liquid circulation chip removal system to effectively reduce cutting temperature and extend tool life. 2 Core advantages 2.1 Processing efficiency and cost control Multiprocess integration greatly reduces the number of clamping times. Compared with the traditional singlemachine processing mode, the efficiency is increased by **5 times, which is especially suitable for products with high production requirements such as brass valves. 2.2 The servo power head can choose the screw tapping method to reduce the tool change time and further shorten the production cycle. 2.3 Modular design supports station function expansion (such as adding inspection stations) to meet the needs of diversified products. |
| 国家: | China |
| 型号: | The vertical multistation combination machine tool is a highefficiency, highprecision automated processing equipment, especially suitable for the mass production of complex parts such as brass valves. It integrates drilling, boring, tapping and other proc |
| 离岸价格: | 100000 ~ 300000 / Piece 获取最新报价 |
| 位置: | China |
| 最小订单价格: | 100000 per Piece |
| 最小订单: | 1 Milligram |
| 包装细节: | 20-40 ft container |
| 交货时间: | 1-3 months |
| 供应能力: | 20 Piece per Month |
| 付款方式: | T/T, L/C |
| 產品組 : | - |
