Automatic Folding Machine Automatic Folding Machine Automatic Folding Machine Automatic Folding Machine Automatic Folding Machine
Next

Automatic Folding Machine

离岸价格

获取最新报价

( Negotiable )

|

1 Set Minimum Order

国家:

China

型号:

-

离岸价格:

( Negotiable ) 获取最新报价

位置:

Made In China

最小订单价格:

-

最小订单:

1 Set

包装细节:

Wooden Cases

交货时间:

7 Days

供应能力:

-

付款方式:

L/C, T/T

现在联系
免费会员

联系人 Ms. Sunny

NO89 phoenix western road ,economic development zone,taizhou,, jiangsu, Other

现在联系

产品规格

  • Material:Stainless Steel

详情

Mainly used for folding the textile such as quilt, match with the ironing machine.
Can fold 2 or 3 lane in each direction ,  totally up to 32 layers.
Double roller and double speed for checking the length for accurate folding.
Computer controlled with display touch screen, selection by size of linen automatically.
I/O self testing and diagnosing function.
Frequency inverter drive with soft start to reduce stress on drive components.
START/STOP pause and restart operation without interrupting folding in progress.
Heavy-duty motor with overloading protection.
Individual air pressure regulators with gauge and auto-drain feature.
Germany Siemens electric parts ,Korea LS inverter.two inverters.
Full safety guard, with interlock and emergency stop .
Static eliminator available to avoid static generation
Special size is available.

ZD型床单被套折叠机主要技术参数:

参数名称Item name 单位 ZD3000-V ZD3300-V
最大折叠长度×宽度Folding length(max.)×width mm 3600*3000 3600*3300
工作能力(普通单床)Working capacity m/min 30 30
使用气源压力Supply pressure Mpa 0.5-0.7 0.5-0.7
压缩空气消耗量Compressed consumption L/min -80 -80
额定输入功率Rated power Kw 1.5+0.75 1.5+0.75
耗电量Power consumption Kw/h 0.6 0.6
配用空气压缩机排量Drainage of air compressor m3/min 0.3 0.3
外形尺寸(长×宽×高)Dimension(L×H) mm 4640*2530*1930 4940*2530*1930
整机重量Machine weight kg 1450 1450
外接电源线径External power line mm2 4自备provided by users 4自备provided by users
电源Power supply VP/HZ 380/3/50 380/3/50


国家: China
型号: -
离岸价格: ( Negotiable ) 获取最新报价
位置: Made In China
最小订单价格: -
最小订单: 1 Set
包装细节: Wooden Cases
交货时间: 7 Days
供应能力: -
付款方式: L/C, T/T
產品組 : Automatic Folding machine
