双层洗脱烘一体机
DOUBLE STACK WASHER EXTRACTOR DRYER AL IN ONE
1 洗涤 脱水 烘干都能在控制面板上 实现集中统一控制。一台机器完全取代传统的的两台洗衣机和烘干机
。整体结构合理紧凑 ，节省100%空间
2 相比于常规的径向式机器，本机器能更有效的利用热能
，缩短干燥时间 更节省成本
3 双层结构占地面积很小，移动方便
，维护方便
4 采用国外最新技术 ，采用变频电机 ，整体性能更稳健 ，小型洗脱烘机器种性价比 最高的一体机
Coin Operated Laundry Stacked Washer and
Dryer 1. Double-layer
structure, saves space.
2. Panel and drum adopt high quality stainless steel, acid and
alkali resistance, anti-corrosion, good appearance, long life.
3. With mechanical suspension shock structure, low noise, free
standing.
4. Simple door system, easily for users.
5. Can read different coins and tokens at the same time, card read
system also available, widely used for all over the world.
6. Door lock system of washer and dryer can protect users.
7. It can work smoothly even high spin speed more than 700 r/min
because of unique suspension
system.
| Model | XGQP-SX12 F | XGQP-SX15F |
| washer capacity(kg) | 12 | 15 |
| drum dimension(mm) | 670*340 | 670*430 |
| rated voltage (kw) | 220/380 | 220/380 |
| frequency power (kw) | 2.2 | 2.2 |
| motor power(kw) | 1.5 | 1.5 |
| heating power(kw) | 5.4 | 6-12 |
| dryer capacity(kg) | 15 | 15 |
| drum dimension(mm) | 750*480 | 750*600 |
| hole diameter(mm) | 1 | 1 |
| main motor power(kw) | 0.12 | 0.12 |
| fan power (kw) | 0.55 | 0.55 |
| heating power (kw) | 7 | 7 |
| total power(kw) | 7.12 | 15.1 |
| steam pressure(mm) | / | 0.4-0.6 |
| steam consumtion (mm) | / | 50-60 |
| steam inlet (mm) | / | DN15 |
| hydrophobic caliber(mm) | / | DN15 |
| exhaust diameter(mm) | 105mm | 105mm |
| Dimension(mm) | 930*900*2080 | 1000*850*2040 |
| Weight(kg) | 580 | 820 |
