HM-ZD600 Automatic Rigid Box Making Machine

China

HM-ZD600

( Negotiable ) 获取最新报价

-

-

1 Set

wooden cases

45 days after receiving the payment

15 Set per Month

L/C, T/T

现在联系

产品规格

Power : 17kw warranty : 1 year after sales service : engineer available abroad air compressor : needed tape type : paper tape, PVC tape tape width : 19mm, 29mm, 39mm

详情

HMZD600 Automatic Rigid Box Making Machine


HMZD600 Automatic Rigid Box Making Machine is a fully automatic machine mainly used to manufacture rigid boxes which is consisted of a cover paper and an inner box, such as gift boxes, phone boxes, big boxes, jewelry boxes, pull up boxes, chocolate boxes, shoe boxes, big boxes, small boxes, cosmetic boxes, watch boxes, chopstick boxes, etc

HMZD600 Automatic Rigid Box Making Machine Features and Functions:

1.Suitable for all kinds of rigid boxes automatic production.

2. The whole computer parametersis set, auto display error and malfunction display.(Standard)

3. Automatic sending and suck in the coverpaper and cardboard.(Standard)

4. 24hours glue preheating.(Standard)

5.Four angle clinging and heating, single manmachine control system for the whole machine.(Standard)

6.Adopt Panasonic PLC and manmachine control system for the whole machine.(Standard)

7. Rectification and positioning system (positioning inaccuracy ≤0.2mm).(Standard)

8. Box automatically leading and suction device (standard)

9. Remodel for automatic production of different kinds of boxes(Optional)

10. Automatic Control System for glue viscosity (Optional)

HMZD600 Automatic Rigid Box Making Machine Parameter:

HMZD600 Automatic rigid box machine
Specification:
Paper Max. size: 610x850mm Paper Min. size: 95x180mm
Box Max. Length: 600mm Box Min. Length: 100mm
Box Max.Width: 400mm Box Min.Width 50mm
Box Max. Height: 130mm Box Min. Height: 12mm
Board Thickness : 13mm Paper Thickness: 80160gsm
Speed : 1830 pcs/min Folding Edge: 1020mm
Machine Power: 13kw Heating Power: 4kw
Machine Measurement: 6800x4500x3300mm


HMZD600 Automatic Rigid Box Making Machine Description and main configuration of the machine

1. Cover paper feeding system and glue coating system

1). 24 hours glue preheating and control system
2).The cover paper automatic sending with feeder system
3).The vacuum suction fan under the conveyer belt can keep the glued paper from deviating


2.Automatic Corner Pasting Machine

1).Automatic feeding cardboard
2).Hotmelting adhesive automatic conveying, cutting and finish pasting the inner box quad stayer(four angles) of cardboard in one process.
3).With independent control system

3. Spotter system
1).The glued paper and cardboard inner box employ hydraulic pneumatic rectifying device and servo device to spot correctly.
2).The spotting accuracy is ±0.2mm.
3).The whole machine employs PLC, photoelectric detector system and touch screen manmachine interface to automatically spot and form the box in one process.
4).Computer control with auto error display and malfunction display.

4.  Automatic Wrapping Part


Automatically collect boxes and deliver them to the forming unit. The boxforming unit can continually delivery boxes, wrap sides, fold ears and paper sides and form in one process.


HMZD600 Automatic Rigid Box Making Machine Delivery time:
30 days after receiving deposit

HMZD600 Automatic Rigid Box Making Machine Installation and after sale service:
After the contracted equipment arrives to the endusers factory, the Seller shall send, after receiving the buyers request, his engineer (in general one mechanical engineer) to the enduser, for installation and commissioning and acceptance test, which shall be completed within15 days.

HMZD600 Automatic Rigid Box Making Machine Packing List:
Packing material: wrapped in PP film and wrapped in wooden cases

Container: one 40 HQ
