MDL-150D Hydraulic Crawler Anchor Drilling Rig :



 This deep foundation anchor crawler drilling rig is a high efficiency drilling rig mainly for anchoring, jet grouting and dewatering. It is all hydraulic operated drill accordance with the requirements of subway, high-rise building, airport and the other deep foundation pit.







1. Advantage:



1.1 Crawler Hydraulic Drilling Rig, Move with the crawler belt, mobile drilling rig, has fast mobility ,accurate location, time-saving, good reliability and stability and other technical feature.



1.2   With 3.4 meters stroke of slide frame, can be applied for 3 meters drill pile drilling,casing composite drilling.



1.3  With clamp holder ( shackle holding device), easy to handling the drill pipe and caing, saving time, saving labor cost, high efficiency.







2. Main Feature:



2.1 Energy-Saving, High Efficiency: the power did not increase, but it improve the work efficiency.



2.2 The maximum speed is up to 170 r/min; in the basis of MDL-135D, makes the speed increased by 20%, when using the twist drill, drilling effeciency even more impressive on the soil.



2.3 The speed increased meanwhile compared with MDL-135D the torque increased by 10%, and the maximum rotary torque increased to 7500NM.



2.4 This drilling rig use the new hydraulic system, the structure is more simple, more reasonable layout, operation more hummanity.



2.5 Compared with MDL-135D drilling rig, the drilling efficiency is enhanced by about 20%.



3. Main Parameter :






































































































Hole diameter(mm)



Φ150~Φ250



Hole depth (m)



130-170



Drill Rod diameter (mm)



φ73,φ89,φ102,φ114/φ127,φ133,φ140,φ146



Hole angle(°)



0-90



Output rotary speed of power head (r/min)



10/20/30/35/40/60/65/70/85/130/170



Output torque of power head (N.m)



7500



Stroke of power head (mm)



3400



Stroke of slide frame (mm)



900



Lifting force of power head (kN)



70



Lifting speed of power head (m/min)



0~5 adjustable,7,23,30



Feeding force of power head (kN)



36



Feeding speed of power head (m/min)



0~10 Adjustable,14,46,59



Input power (electromotor engine) (kW)



55+18.5



Dimension in Transportation status (L*W*H) (mm)



5400*2100*2000



Weight (kg)



6000



Walking Parameter



Walk way



Through track ( crawler belt)



Climbing angle (°)



25



Track ground contact pressure (KPa)



37.8



Walk speed (Km/h)



0.4



Rotation Parameter



Rotation way



Manual rotating



Rotation structure



Rotating bearing



Location way



Locating bolt



Remark:Technical specifications are subject to change without prior notice and incurring responsibility for machines previously sold.
