Beijing FANCH Machinery Co., Ltd

No.16 Guanghua Road, Tongzhou Industrial Development Zone, Beijing, China,Beijing,Beijing,China

查看电话号码

免费会员

Single Spindle CNC Router Machine

China

FC-I6-1D

7200 ~ 7500 / Set ( Negotiable ) 获取最新报价

China

7200 per Set

1 Set

Plywood Case

15 days

50 Set per Year

T/T

现在联系

产品规格

X Y axis travel : 1300*2500mm Z axis travel : >200mm Table size : 1340*2500mm Resolution : ñ0.001mm Max running speed : 25m/min Max feeding height : 200mm Spindle : China 6.0KW air-cooling Spindle speed : 6000-18000rpm/min Control system : NC Studio Work mode : Stepper Work voltage : AC380V/50Hz

详情

Product Catalog
Item No.: FC-I6-1D(1300*2500*250mm,
China 6.0KW air-cooling spindle)
(This is reference picture but appearance is similar with picture)
Unit Price:FOB Tianjin Port
*Package: Plywood Case
MOQ: 1 set
Payment: By T/T 40% down payment before production and the60% balance paid before shipment.
Delivery Time: 25days
Warranty: One year

Features:

Machine Bed: High-quality steel structure welding seamless
Machine Parts: Aluminum casting
Spindle: China 6.0KW air-cooling spindle
Driver: Shenzhen LEADSHINE hybrid servo
Motor:Stepper
Transmission: Imported synchronous belt-pulley transmission
Control System: Shanghai NC Studio
Inverter: Shenzhen INOVANCE
Linear Guide Rail:Taiwan HIWIN 30mm (X/Y axis) and 25mm (Z axis)
Rack and Pinion:TaiwanXINYUE (X/Y axis)
Ball Screw:Taiwan TBI (Z axis)
Working Table: Vacuum adsorption
Electrical Components: French Schneider, Taiwan AirTAC
Parameters:
X Y axis travel 1300*2500mm
Z axis travel >200mm
Table size 1340*2500mm
Resolution ±0.001mm
Max running speed 25m/min
Max feeding height 200mm
Spindle power China 6.0KW air-cooling
Spindle speed 6000-18000rpm/min
Control system NC Studio
Software operating environment Windows98/2000/XP
Command language G code.uoo.mmg.plt
Work voltage AC380V/50Hz
Work mode Stepper
