Airmobi V21 Full Electric VTOL Drone - UAV Platform -90 Minutes @ 1.5kg

* 3 hours flight endurance (180 minutes) when unloaded
* 2 hours flight endurance (120 minutes) with 1.2kg payload
* 90 minutes flight endurance with 1.5kg payload

The Airmobi V21 is a high-performance, long-endurance tail-push vertical take-off and landing (VTOL) fixed-wing UAV, designed to excel in long-distance inspection and surveying missions. With a remarkable 3-hour flight time when unloaded, and the ability to carry a 0.5kg payload for 2 hours, this UAV is perfectly suited for extended missions that require precision and reliability. The aircrafts robust construction, utilizing carbon fiber, fiberglass, Kevlar, and PVC, ensures durability and lightweight efficiency.

1. Exceptional Endurance: Capable of flying for 3 hours when unloaded, or for 2 hours with a 0.5kg payload, making it ideal for long-distance operations.
2. Advanced Materials: Constructed with carbon fiber, fiberglass, Kevlar, and PVC, offering a strong yet lightweight airframe.
3. Optimized Design: The landing gear is strategically placed below the rotor arms, while the payload bay is centered beneath the aircrafts center of gravity, ensuring optimal balance and stability.
4. Versatile Mission Capability: Ideal for tasks such as long-range inspections and high-precision mapping, with the ability to operate in diverse and challenging environments.
5. Wind Resistance: Designed to withstand winds up to 6 on the Beaufort scale in fixed-wing mode, and up to 4 in rotor take-off and landing mode, ensuring operational reliability in various conditions.
6. All-Weather Operation: Operates efficiently in temperatures ranging from -20°C to 45°C, and can safely fly in light rain.

• Material: Carbon fiber, fiberglass, Kevlar, PVC
• Structure Weight: Approximately 2650g (including all structural components and mounting parts)
• Maximum Takeoff Weight: 10kg
• Maximum Payload Capacity: 1.5kg (Standard payload: 1kg)
• Wing Area: Approximately 80 dm²
• Wing Loading: Approximately 125g/dm² @ 10kg
• Endurance:
  • 3 hours (180 minutes) when unloaded
  • 2 hours (120 minutes) with a 0.5kg payload (measured near sea level in calm conditions)
• Maximum Control Range:
  • Manual Control: 0.5km-1km
  • Ground Station: 5km-30km
• Standard Cruise Speed: 18m/s @ 10kg (19m/s recommended for mountainous operations)
• Maximum Cruise Speed: 93.6km/h (26m/s)
• Standard Battery Configuration: 22.8v/25Ah * 1 (22.8V)
• Never-Exceed Speed: 122km/h (approximately 34m/s)
• Stall Speed: 14m/s @ 10kg (14m/s @ roll 25°/pitch 15°)
• Minimum Turning Radius: 100m @ 18m/s (safe turning radius not less than 200m in high-altitude conditions)
• Maximum Flight Altitude: 4800m above sea level
• Wind Resistance:
  • Fixed-Wing Mode: Up to Beaufort scale 6 (gusts up to 7)
  • Rotor Take-off and Landing Mode: Up to Beaufort scale 4 (gusts up to 6)
• Operating Environment: -20°C to 45°C; capable of flying in light rain (safe operation time exceeds 10 minutes)
• Rotor Emergency Operation Time: Not less than 6.5 minutes (with independent rotor battery, non-standard power configuration)
• Take-off and Landing Method: Vertical take-off and landing
• Rotor Propeller Size: 16 inches (recommended)
• Fixed-Wing Tail-Push Propeller: 15-18 inches (recommended)
• Safe Voltage When Entering Landing Pattern: Not less than 22.4V (for Gens Ace high-voltage batteries)
• Wing Installation Angle: 2°
• Body Length: 930mm
• Wingspan: 2150mm
• Landing Gear Height: 155mm

The Airmobi V21 is a versatile and reliable UAV platform, offering long endurance, robust performance, and exceptional flexibility for a wide range of professional applications.
