离岸价格
获取最新报价3.25 USD / Piece ( Negotiable )
|100 Piece Minimum Order
国家:
China
型号:
4D0/4D1/4D2/4D3
离岸价格:
3.25 USD / Piece ( Negotiable ) 获取最新报价
位置:
China
最小订单价格:
3.25 per Piece
最小订单:
100 Piece
包装细节:
Standard packing or according to customers request.
交货时间:
12-25 working days
供应能力:
10000 Piece per Month
付款方式:
Other, T/T
產品組 :
联系人 Mr. bill
Changan, Dongguan, Guangdong
Solar MC 4 blocking diode
connector for solar system 4D0/4D1/4D2/4D3
Note: Prices excluding
diode.
| Product Specifications | |||||||||
| Insulation material | PPE/PA | Overvoltage category/Pollution degree | CATIII/2 | ||||||
| Rated current(Without diode) | 30A | Safety degree | II | ||||||
| Rated current(With Diode) | 10A(Diode Rated Current 15A) | Flame class | UL94-V0 | ||||||
| Rated voltage | 1000VDC | Insertion force/Withdrawal force | ≤50N / ≥50N | ||||||
| Test voltage | 6kV(50Hz,Imin) | Ambient temperature range | -40℃…+85℃(IEC) | ||||||
| Typical contact resistance | ≤0.25 mΩ | Upper limiting temperature | 110℃(IEC) | ||||||
| Contact material | Copper,Tin plated | Connecting system | Crimp connection | ||||||
| Degree of protection | IP67 | Nut cap locking force | 1.5-1.8Nm | ||||||
| 国家: | China |
| 型号: | 4D0/4D1/4D2/4D3 |
| 离岸价格: | 3.25 / Piece ( Negotiable ) 获取最新报价 |
| 位置: | China |
| 最小订单价格: | 3.25 per Piece |
| 最小订单: | 100 Piece |
| 包装细节: | Standard packing or according to customers request. |
| 交货时间: | 12-25 working days |
| 供应能力: | 10000 Piece per Month |
| 付款方式: | Other, T/T |
| 產品組 : | Diode connector |
