离岸价格
获取最新报价4.8 ~ 4.08 USD / Piece ( Negotiable )
|500 Piece Minimum Order
国家:
China
型号:
4F0-15/4F1-15/4F2-15/4F3-15
离岸价格:
4.8 ~ 4.08 USD / Piece ( Negotiable ) 获取最新报价
位置:
China
最小订单价格:
4.8 per Piece
最小订单:
500 Piece
包装细节:
Standard packing or according to customers request.
交货时间:
10-15 working days
供应能力:
20000 Piece per Day
付款方式:
Other, T/T
產品組 :
联系人 Mr. bill
Changan, Dongguan, Guangdong
Solar 1500VDC MC4 inline fuse
connector for solar
system 4F0-15/4F1-15/4F2-15/4F3-15
Note: Prices excluding
fuse.
| 1500VDC PV 4.0 Fuse Connector | |||||||||
| Product Specifications: | |||||||||
| Insulation material | PPE/PA | Fuse Specification | 1A-50A | ||||||
| Rated current(Without fuse) | 50A | Safety degree | II | ||||||
| Rated voltage | 1500VDC | Flame class | UL94-V0 | ||||||
| Maximum voltage(With fuse) | 1575V | Ambient temperature range | -40℃…+85℃(IEC)* | ||||||
| Contact resistance | ≤0.25 mΩ | Upper limiting temperature | 110℃(IEC) | ||||||
| Contact material | Copper,Tin plated | Suitable cable cross sections |
2.5~10mm2 /14~8AWG (4F1-15~4F3-15) |
||||||
| Degree of protection | IP68(1m,1H) | Suitable for fuse size(mm) | 10*85 or 10/14*85 | ||||||
| Rated Impulse voltage | 16KV | Regulatory approval | TUV,CE | ||||||
| 国家: | China |
| 型号: | 4F0-15/4F1-15/4F2-15/4F3-15 |
| 离岸价格: | 4.8 ~ 4.08 / Piece ( Negotiable ) 获取最新报价 |
| 位置: | China |
| 最小订单价格: | 4.8 per Piece |
| 最小订单: | 500 Piece |
| 包装细节: | Standard packing or according to customers request. |
| 交货时间: | 10-15 working days |
| 供应能力: | 20000 Piece per Day |
| 付款方式: | Other, T/T |
| 產品組 : | Fuse connector |
